DETAILS

• Platform

  Trail
• Model Name

  Trail 6
• Model Code

  C26601M

FRAMESET

• Frame

  SmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
• Fork

  SR Suntour XCT, 100mm, coil, 42mm offset (27.5") 46mm offset (29")
• Headset

  Semi-Integrated, 1-1/8"

DRIVETRAIN

• Rear Derailleur

  Shimano Acera
• Front Derailleur

  Shimano Altus, 34.9 clamp
• Shifters

  Shimano M315 Rapidfire Plus, 8-speed
• Chain

  KMC X8, 8-speed
• Crank

  Prowheel, 36/22
• Rear Cogs

  Sunrace, 11-34, 8-speed
• Bottom Bracket

  Sealed bearing cartridge, square taper

BRAKES

• Brakes

  Tektro M275 hydraulic disc, 160/160mm rotors
• Brake Levers

  Tektro hydraulic disc

WHEELS

• Rims

  WTB SX19, 32h
• Front Hub

  Shimano HBTX 505
• Rear Hub

  Shimano FHTX505
• Spokes

  Stainless Steel, 14g
• Tires

  WTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
• Tire Size

  2.25
• Wheel Size

  29
• Front Tire

  WTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
• Rear Tire

  WTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound

COMPONENTS

• Handlebar

  Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
• Stem

  6061 Alloy, 31.8, 7°
• Grips

  Cannondale Dual-Density
• Saddle

  Cannondale Stage 3
• Seatpost

  Cannondale 3, 6061 Alloy, 31.6 x 350mm (XS - SM), 400mm (MD-XL)
